Packet Power's Wireless Network Connector provides an easy way to make supported metered devices not connected to a network work over Packet Power's wireless network. We've just added more supported devices so you'll have fewer stranded smart devices.
Wireless Network Connector Features
- Auto-detects select smart devices from a number of manufacturers
- Instantly connects to Packet Power's self-configuring, self-optimizing wireless mesh network
- Use the local LCD to immediately verify correct operation
- Supports up to two optional temperature probes
- Can be mounted with a low profile bracket, via a DIN rail clip, or by optional magnet
- Powered by external 100-240V power supply (works with most plug types including C13); some power strips can power the WNC directly from USB or other ports
Supported Devices
| Brand |
Device type |
Models* |
| APC |
Power strip |
Supported AP78XX, 79XX and 88XX models |
| APC |
ATS |
Supported AP77XX models |
| Austin Hughes |
Power strip |
InfraPower with IP Dongle |
| Geist |
Power strip |
Monitored units using IMD-02 and IMD-03 meter platforms |
| Janitza |
Power meter |
UMG 96RM |
| Liebert (Vertiv) |
Power strip |
MPH devices using RPC-2 communication module |
| RLE |
Leak detection controller |
LDRA6 |
| Schneider |
Power meter |
PM5XXX |
| Servertech |
Power strip |
Supported PRO2 CDUs |
* May not be compatible with all firmware release levels and configuration settings
New supported devices are added regularly. Please contact info@packetpower.com to discuss the process for adding new devices.
Easy access to data
Customers with existing monitoring applications can access data sent by the WNC via a Packet Power Ethernet Gateway using standard protocols such as SNMP, Modbus TCP/IP, Ethernet/IP and MTConnect. Support for BACnet/IP and MQTT protocols is coming early 2021. Packet Power's EMX Energy Portal provides an easy-to-use option for customers that have yet to deploy a monitoring application.
See more information about the Packet Power Wireless Network Connector
Packet Power Team
Packet Power Team : Mar 6, 2023, 7:28:01 AM
